Alpine i509-WRA-JK Digital Multimedia Receiver for Jeeps

Product highlights

General Features:

• digital media receiver with AM/FM tuner (does not play discs)
• custom-fit receiver designed for select 2011-18 Jeep Wrangler JK models
• includes Alpine Restyle package with all installation parts
• 9" capacitive touchscreen with high-resolution (1280x720 pixels) display
• splash-proof and dust-proof touchscreen and bezel (IP53-rated)
• Bluetooth hands-free calling and audio streaming (external microphone included)
• includes iDatalink Maestro ALP-MRR module (requires Windows PC for programming)
• retains factory features, including steering wheel controls
• displays engine performance data on touchscreen
• HD Radio tuner built-in

Smartphone Features (see Details for info on compatibility with specific smartphones and apps):

• Apple CarPlay compatible (wired and wireless)
• Android Auto compatible (wired and wireless)
• built-in iPod, iPhone, and iPad control
• playback and control of music files on compatible Android devices
• full Tidal integration with custom display (requires a wi-fi connection and Tidal smartphone app)

Audio/video Features:

• plays MP3, WMA, AAC, WAV, APE, and FLAC music files (see Details tab for full capabilities)
• plays AVI, MP4, MPG, MOV, and WMV video files
• 13-band parametric equalizer (Basic or Advanced)
• 6-channel time correction
• 10 EQ preset curves
• high- and low-pass crossovers
• Bass Engine SQ
• MediaXpander HD

Expandability:

• works with SiriusXM SXV300 tuner—supports Tune Mix, Traffic & Weather Now, and Sports Flash features
• compatible with optional Alpine DVE-5300 DVD player
• inputs: 2 rear USB ports; rear HDMI input; rear auxiliary input; 2 camera inputs (RCA)
• outputs: rear HDMI output; 6-channel preamp outputs (4-volt front, rear, subwoofer)

Other Information:

• built-in amplifier (18 watts RMS CTA-2006/50 peak x 4 channels)
• wired connection to parking brake required to access settings, video display, and other features on this receiver (the parking brake must be connected and set, released, and set again)
• warranty: 1 year

What's in the box

• Alpine iLX-F509:
• 9" Touchscreen monitor
• Source unit
• Wiring harness (15A fuse)
• Preout harness
• iDatalink/Driver Recorder/Front Camera harness
• Camera input adapter harness
• Mic/SWC harness
• Microphone (w/ attached 12.5' cable terminated by a right-angle stereo-3.5mm connector)
• Surface-mount bracket
• Two-sided tape
• GPS antenna (attached 8' cable with proprietary connector)
• Self-adhesive mounting pad
• 3 Self-adhesive cable clamps
• Power-plate
• 2 Rear covers
• HDMI connector clamp
• 4 Pan-head ISO-screws (M5x8mm)
• 4 Counter-sunk ISO-screws (M5x8mm)
• 3 Display screws (M5x8mm)
• 2 Hinge screws (M3x4mm)
• 2 Rear cover screws (M2.6x6mm)
• 4 Rectangle self-adhesive sheets
• 4 Square self-adhesive sheets
• 2 Round self-adhesive sheets
• 2 Semi-oval self-adhesive sheets
• Quick Reference Guide
• Online Registration Information
• Online Detailed Manual Card
• Maestro ALP-HRN-WRA5:
• iDatalink Maestro RR radio replacement interface module (ALP-MRR)
• Main harness
• Antenna adapter
• USB flashing cable
• SAT radio antenna adapter
• OBDII harness
• Power/ground harness
• Alpine G-KTX-WJK:
• Radio dash bezel
• 2 Side brackets
• 2 Display brackets
• Display/power key harness
• Installation Manual
• "Read Before Installation" Note. Online Registration sheet
• Warranty Information

About this item

Written by Crutchfield's Dominic DeVito

Your JK deserves a top-of-the-line Alpine

Alpine's long been synonymous with first-class automotive audio, and the i509-WRA-JK digital multimedia receiver is no exception. This handsome Restyle package fits your 2011-18 Wrangler JK, combining seamless (and wireless) smartphone connectivity, HD Radio™, plenty of inputs, and much more with rugged construction that can handle the challenges of your Jeep's environment. Alpine tricked out this new radio with a high-resolution display and audio enhancements that make it a treat for both your eyes and ears.

Designed for your Wrangler

This Alpine Restyle package lets you install the i509-WRA-JK in pretty much every 2011-18 Wrangler JK model. This package contains a dash kit that houses the weather-resistant receiver, along with wiring adapters that plug directly into the factory electronics and wiring. Alpine even includes an iDatalink module that allows you to keep your steering wheel audio controls and the Jeep Uconnect® features you've grown fond of. Once you've identified your vehicle, we'll tell you if this Jeep kit fits.

Matches your Jeep style and Jeep lifestyle

The Restyle dash kit comes with custom keys that match the lighting, color, shape, and style of the factory keys, and it also lets you keep your climate controls. Buttons along either side of the 9" display offer easy access to commonly used functions, and you'll even retain your Jeep's 12-volt ports.

Your Jeep is designed for off-road use, and so is this receiver. The bezel and touchscreen are splash-proof and dust-proof, so you can drop the top and head into the wilderness without worrying about your receiver succumbing to the elements.

Works with both wired and wireless Android Auto™ and Apple CarPlay®

This Alpine's compatible with both Apple CarPlay and Android Auto, so you and your passengers can enjoy messaging, mapping, tune selection, and much more from your smartphone without touching any screens. Both platforms work with voice commands, which you can activate by speaking a keyword or pressing the dedicated "Voice" button on the stereo's bezel. You can get stuff done without being distracted by your phone, and you can use either platform with your phone plugged in or wirelessly. Get more info at www.apple.com/ios/carplay and www.android.com/auto.

Connections for your sources

Even without a disc player, the iWRA-509-JK offers lots of ways to enjoy your media. Dual rear USB inputs let you attach your smartphone or a thumb drive with your favorite music or video files. The rear HDMI connection allows you to hook up to an optional CD/DVD or Blu-Ray player. An auxiliary input lets you bring in audio from another source, such as an old-school portable disc player. When your smartphone is connected, this Alpine's ready to roll with your favorite streaming services. Pull up playlists, albums, and more with ease, and check out the information on the i509-WRA-JK's gorgeous display.

Tidal users will have full array of the service's high-res audio offerings at their disposal, with a custom app interface right on the radio's display. You can explore it all when you're connected to a wi-fi hotspot, and some Tidal features may require a subscription.

Built-in Bluetooth®

The i509-WRA-JK continues Alpine's long relationship with Bluetooth connectivity. Use it to make or receive hands-free phone calls via your smartphone with the included microphone, or stream music from your phone with ease. You can also use the included microphone to activate voice commands for Apple CarPlay and Android Auto.

Radio you can groove to

The i509-WRA-JK boasts excellent entertainment choices up and down the dial:

• HD Radio reception: Enjoy crystal-clear sound quality from participating AM and FM stations, including FM that sounds almost as good as a CD. Plus, you'll see station and song info on the screen.

• Satellite radio compatibility: You can add SiriusXM programming to the receiver with an optional tuner and a subscription.

High-resolution display

We live in an 8K world now, so there's no reason your stereo's screen can't look a little better. Alpine gave this display a resolution of 1280 x 720 pixels, so your album artwork and other information will be clear and focused. When you're parked and checking out some video, the i509-WRA-JK can act as a drive-in theater — just bring your own popcorn.

Heavy-duty audio performance

The i509-WRA-JK's not only a pretty face, it also boasts plenty of ways to keep your ears happy. You can use its many fingertip-friendly controls to set the EQ — this Alpine offers both Basic and Advanced tuning options, with 13-band parametric adjustments, time correction, and much more.  And it works with lossless FLAC files to give you the thrilling digital media experience you crave. You'll be sure to hear the results thanks to Alpine's commitment to using high-quality audio components, such as a full-digital power integrated circuit and custom capacitors to keep the signal strong, clean, and free of noise.

Ready for your rear-view and dash cameras

Rear-view camera owners will appreciate the included camera input and distance guidance display. It also works with Alpine's advanced HD dash cam/rear-view cam combo for all-over coverage of your vehicle. And if you'd like to add Alpine's optional HCE-C2100RD multi-view camera, you'll need this 2-camera switcher (not included) as well.
